EDIRYX Ultra

HydroPurilexology

Hydropurilexology™ – The Science of Water, Purification & Intelligence
At the heart of EDIRYX lies Hydropurilexology™, our proprietary framework that unites water chemistry, advanced purification technologies, precision instrumentation, intelligent control, and complete data representation into one integrated science.

It ensures not only the highest purity water, but also delivers:
• Secure, multi-level user logins
• Automatic data logging & audit trails
• Real-time water quality monitoring
• Event, error, and consumable replacement tracking

Hydropurilexology™ integrates multiple purification stages, including:
• Reverse Osmosis (RO): Primary desalination and impurity removal
• Electrodeionization (EDI): Continuous polishing to ultrapure levels
• Ultraviolet (UV): Dual wavelength for TOC reduction (185 nm) and microbial control (254 nm)
• TOC Monitoring: Real-time assurance of organic contamination levels
• Programmable Dispensing: Accurate, calibrated volume delivery
• Integrated Automated Disinfection System (ADS)

A key pillar of Hydropurilexology is the Automated Disinfection System (ADS). ADS ensures that every water pathway remains sterile and contamination-free, without manual intervention. By combining sensor-driven monitoring, timed UV or chemical disinfection cycles, and automated alerts, ADS guarantees:

Continuous microbial control across storage tanks and pipelines
Minimal maintenance intervention.
Seamless integration with central monitoring systems, plus automated documentation of disinfection cycles for compliance and audits
With ADS embedded in Hydropurilexology, laboratories and high-end facilities benefit from complete, automated water hygiene, complementing the precision, efficiency, and intelligence of the entire water purification system.

With Hydropurilexology™, purification goes beyond hardware — it becomes a total ecosystem of water, intelligence, and compliance, perfectly aligned with EDIRYX™’s promise of Leading Exacting Standards.


Specification

Specification Specifications Value or Range
Pressure 2 - 7 bar
Flow rate 500 - 2500 ltr/hr
Feedwater Type Ideally potable tap water
Conductivity < 2500 μS/cm
pH 4 - 10
Hardness ppm upto 800ppm (with Mix Multi XL)
Silica < 30ppm
CO2 < 30ppm
SDI (Silt Density Index) <12
Free Chlorine < 3ppm
TOC (Total Organics) < 2000ppb
Specification Specifications
Type II Generation Rate (ltr/hr) 100, 175, 250 (Customized generation rates available)
Type II Conductivity < 0.2μS/cm (Typically 0.067 - 0.1μS/cm)
Type II TOC < 50ppb
Bacteria Count (Tank Water) < 1CFU/ml (With ADS)
Dissolved Silica < 3ppb
Type I Generation/Dispensing Rate (ltr/min) upto 20ltr/min (Adjustable as per requirement)
Type I Conductivity 0.055μS/cm
Type I TOC < 10ppb
Type I Real Time TOC monitor and display Yes
Type I Bacteria Count (At Dispensing Point) < 0.1CFU/ml (With POU 10" 0.2μm filter)
Specification Specifications
Tank Size 100 - 1000 ltr
Tank Material SS316 with electropolished internal surface & MOC certification
Distribution Pump Two pumps can be installed that work simultaneously
Specification Dimensions & Weight
Dimensions for all EDIRYX Flow rates (all figures in mm) W 600 X D 600 X H1900
Weight
EDIRYX 100 110 kg Nett. Shipping Weight 150kg
EDIRYX 175 125kg Nett. Shipping Weight 165kg
EDIRYX 250 140kg Nett. Shipping Weight 180kg
Specification
06.1252
19200022
19200024
06.5002
SS 05.5100
SS 06.5200
SS 06.5300
SS 06.5500
SS 06.51000
19.0056

Tools

Configurator

The system configuration is done over 4 sections:

Pretreatment + Prefiltration
EDIRYX Capacity
Tank Capacity (One distribution pump is standard, Additional Distribution Pump can be configured)
Recirculation Cartridge - Specify if you need recirculation cartridge or not
Number of Dispensing Points

All above parts make a workable configuration for your needs. Please contact us for any clarification or support to configure the EDIRYX system.
